Deye Storage Grid Inverter , Deye Hybrid Inverter 5kW

Name: Deye Storage Grid Inverter , Deye Hybrid Inverter 5kW
Brand: Deye
SKU: SUN-5K-SG04LP1-EU
Price: 2400000 vnd
Availability: InStock

Feature Description:

Touch LCD screen, easy to install: The Deye 5kW grid-tied inverter is equipped with a handy touch-screen LCD, making it easy for users to set up and adjust functions. Deye Storage Grid Inverter , Deye Hybrid Inverter 5kW

IP65 Waterproof Design: With an IP65 waterproof design, the Deye inverter ensures absolute protection in wet, rainy or harsh weather conditions.

6 battery charge/discharge modes: This inverter provides 6 flexible battery charge/discharge modes, which optimizes the charging and discharging process based on usage needs.

Maximum charge/discharge current 120A: With a maximum charge/discharge current of up to 120A, Deye inverters are capable of handling large amounts of electricity efficiently and effectively.

Integrate 16 machines into a 3-phase/1-phase combination: Deye 5kW allows up to 16 machines to be integrated into a 3-phase or 1-phase combination, enhancing operability and flexibility in use.

Combined with grid-tied inverter: This inverter has the feature of combining with grid-tied inverter, helping to optimize the use of electricity from the grid.

Generator connection port: There is an independent connection port with the generator, allowing the integration and use of power from this source when needed.

48V Battery Voltage: With 48V Battery voltage, Deye inverter ensures safe and reliable voltage for solar power system.

Flexible remote grid push capacity setting: Users can flexibly set the grid thrust capacity remotely, adjusting the operation according to actual needs. Deye Storage Grid Inverter , Deye Hybrid Inverter 5kW

5-year warranty, Wi-Fi included: The product comes with a 5-year warranty and comes with convenient Wi-Fi connectivity for remote monitoring and management.

Outstanding Features of Hybrid Inverter – DEYE Hybrid inverter 5kW

Various modes

Grid modes; storage; Independent and load tracking are integrated to support the use needs of each investor

Support against reverse load on the grid for grid-tied solar power systems, with Single phase CT solution. Deye Storage Grid Inverter , Deye Hybrid Inverter 5kW

Deye Storage Grid Inverter , Deye Hybrid Inverter 5Kw Sun-5K-Sg04Lp1-Eu

Easy to use

Easy to transport and install due to its lightweight design

Monitoring is done by Smartphone

Due to many operating modes, it is very flexible during construction and installation

Compatible with a wide range of storage batteries, accumulators and generators

Deye Storage Grid Inverter , Deye Hybrid Inverter 5Kw Sun-5K-Sg04Lp1-Eu

Guaranteed safety

Natural protection and cooling mode.

Built-in backup function and safe to use. Deye Storage Grid Inverter , Deye Hybrid Inverter 5kW

Safer operation through smart devices for continuous monitoring

Deye Storage Grid Inverter , Deye Hybrid Inverter 5Kw Sun-5K-Sg04Lp1-Eu

Meet quality standards

Effectively reduce electricity bills as self-consumption rate can be improved by up to 80%

DC/AC ratio up to 1.3 so it is very suitable for double glass PV module

Peak efficiency at MPPT is up to 97.6%. Deye Storage Grid Inverter , Deye Hybrid Inverter 5kW

Specifications of Inverter Hybrid Deye 5KW

Model	SUN-5K-SG04LP1-EU
Battery/Battery Specifications
Suitable battery type	Lead Acid Battery or Li-on / Lithium Battery
Battery voltage range (V)	40~60V
Maximum charging current (A)	120A
Maximum discharge current (A)	120A
Symbol graph when charging	3 Stages / Balance
Detachable temperature sensor	Option
Li-ion Battery Charging Method	Self-adaptation to BMS
PV Input parameters
Maximum DC Input Power (W)	6500W
Rated Input PV Voltage (V)	370V (100V~500V)
MPPT voltage range (V)	125~425V
PV voltage at full load (V)	240~425V
Starting voltage (V)	150V
Input PV current (A)	13A+13A
Maximum short circuit current (A)	17A+17A
Number of MPPT	2
Number of strings per MPPT	1+1
AC . parameter
Rated power grid connection and standby (W)	5000W
Maximum power output to the grid (W)	5500W
Standby peak power	Twice the rated power within 10 seconds
Rated current to the mains (A)	21.7A
Maximum current to the grid (A)	25A
Maximum transfer AC current (A)	35A
Power factor	~1 (Adjustable +/- 0.8)
Rated output frequency and voltage	50/60Hz; 220/230 / 240Vac (1 phase)
Grid connection system	1 Phase
Total harmonic distortion	THD<3% (Linear Load<1.5%)
Efficiency
Greatest performance	97.60%
European Performance	96.50%
MPPT performance	99.90%
Protection ability
PV . input lightning protection	Integration
Protection against island splitting	Integration
PV . input polarity reverse protection	Integration
Insulation resistance detection	Integration
Excess current monitoring	Integration
Output overcurrent protection	Integration
Output short circuit protection	Integration
Output overvoltage protection	Integration
Protection against lightning surges	DC protection class 2 / AC protection class 2
Certifications and Standards
Grid standards	VDE 0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116, IEC61727, RD1699: 2011, XP C15-712-3: 2019-05
Safety standards	IEC62109-1, IEC62109-2
EMC	EN61000-6-1, EN61000-6-3
General specifications
Operating Temperature Range (℃)	-25~60℃, >45℃ decrease in efficiency
Cooling	Smart cooling
Noise level (dB)	<30 dB
Communicating with BMS	RS485; CAN
Weight / kg)	20.5
Dimensions (mm)	330W×580H×232D
Protection level	IP65
Shelf	Wall Hanging
Guarantee	5 years
